Land Rover Defender: HD radio

HD RADIO CONTROLS

Do not adjust the touchscreen controls, or allow the system to distract the driver, while the vehicle is moving.

Driver distraction can lead to accidents, potentially causing serious injury or death.

HD Radio systems provide digital radio broadcasts on AM/FM radio, alongside the analog radio signals. HD Radio technology is capable of providing improved audio quality, compared with the analog broadcast.

HD Radio technology operates in a very similar way to the standard AM/FM system. Further information on storing stations, waveband selection, etc., can be found in the relevant section of the Owner's Handbook.

When an HD Radio signal is detected and received, the tuner gradually blends automatically between the analog and the digital audio.

Areas of poor reception due to signal masking and transmitter strengths can affect the HD Radio broadcasts. The HD Radio system may frequently switch between the HD Radio primary signal and the corresponding analog broadcast. If tuned to a multicast service, the audio may mute more frequently.

Note: During this process, a change in volume levels may be experienced. The volume matching between the analog and digital signal is dependent upon the broadcaster.

Note: If poor reception and auto switching becomes unacceptable it is recommended that HD is switched off. Alternatively, tune the radio to an HD Radio service with better coverage.

The HD Radio digital signal is transmitted at the same frequency as the analog signal and can also provide extra multicast services, where available.

To view or alter the HD settings:

1. From the AM or FM radio screen, touch the settings icon.¹ 2. From the system settings screen, touch the AM FM RADIO soft key.

3. HD: Toggle on or off. Toggle on to activate and view the available options.

HD Radio technology is manufactured under license from Xperi Corp. U.S. and Foreign Patents. HD Radio and the HD Radio logo are proprietary trademarks of Xperi Corp.

The HD logo and numbers, underneath the broadcasting station information display, denote the availability of HD and which SPS, if any, is selected.

Tuning to Multicast services

Multicast services (extra supplemental program services) can be received on HD Radio channel broadcasts.

The availability is dependent upon the channel broadcaster.

To access any available multicast services, use one of the following options:

• Touch the seek buttons on the touchscreen. The selected service, HD2, HD3, or HD4, is displayed.

  Note: If the last of the multicast stations is passed when using the seek arrows, the next analog station is selected.

• Touch the STATIONS soft key and select from the multicast services displayed.

Multicast channels can be stored as favorites and used as normal. When recalling multicast favorites, a short delay may be experienced, during which the audio is muted.

If the signal is lost when listening to a multicast service, the audio is muted.

Settings icon.¹
